Zoom H1essential 2-Track Stereo Handy Recorder

INPUTS:

• Built-in mic:
  • 90º XY stereo format
  • Directionality: Unidirectional
  • Sensitivity: –37 dB/1 Pa at 1 kHz
  • Maximum sound pressure input: 120 dB SPL
• MIC/LINE IN jack:
  • Connector: Stereo mini jack
  • Input impedance: 2 kΩ or more
  • Plug-in power: 2.5 V
• Built-in mic:
  • 90º XY stereo format
  • Directionality: Unidirectional

OUTPUTS:

• PHONE / LINE OUT jack:
  • Connector: Stereo mini jack
  • Maximum output level: 20 ｍW + 20 ｍW(into 32Ω load)
  • Output impedance: 10 Ω or less
• Built-in speaker:
  • Type: 20 x 30mm oval dynamic speaker
  • Practical maximum output: 250mW

RECORDER:

• Recording formats:
  • WAV
  • 44.1/48/96 kHz、32-bit Float
  • Stereo / Mono
  • BWF and iXML formats supported
• Recording media:
  • 4–32GB cards compatible with the microSDHC specification
  • 64GB–1TB cards compatible with the microSDXC specification

DISPLAY:

• OLED: 128 x 64

USB:

• Connector:
  • USB Type-C
  • Use a USB cable that supports data transfer.
• USB Mic:
  • USB 2.0 High Speed
  • 48 kHz, 24-bit
• File transfer: USB 2.0 High Speed

POWER:

• 2 AAA batteries: Alkaline, Lithium, or Rechargeable NiMH
• AC adapter:
  • ZOOM AD-17: DC 5 V/1 A
  • USB bus power is supported.

ESTIMATED CONTINUOUS OPERATION TIME USING BATTERIES:

• Alkaline batteries: About 10 hours
• NiMH batteries (800 mAh): About 9 hours
• Lithium batteries: About 18 hours
• POWER CONSUMPTION: 5 W maximum
• DIMENSIONS: 53.9 mm (W) × 136.6 mm (D) × 29.0 mm (H)
• WEIGHT (INCLUDING BATTERIES): 92 g

Warranty: 1 year
