Adam Audio T8V 8-inch Active Studio Monitors
The T8V is an affordable, professional 2-way powered studio monitor with an 8˝ woofer and ADAM Audio’s latest addition to the T Series. Designed around the same technology, features and build quality as its smaller siblings, the T8V provides best-in-class characteristics and sound performance.
Features:
- U-ART 1.9” Accelerated Ribbon Tweeter with HPS Waveguide
- Polypropylene 8” woofer and rear-firing bass-reflex port
- Cumulated Amp. Power RMS: 90 W
- Frequency Response: 33 Hz - 25 kHz
- Max. SPL Per Pair at 1 m: ≥118 dB
Recommended Products
Prepaid Product
Customer Also Viewed
Samma3a Review
Technical Specification
WOOFER:
- Number: 1
- Basket Ø: 8" (203 mm)
- Cone Material: Polypropylene
TWEETER:
- Number: 1
- Type: U-ART
- Diaphragm Area: 4 inch² (2420 mm²)
- Equiv. Diaphragm Ø: 1.9" (48 mm)
- Velocity Transform Ratio: 4:1
- Diaphragm Weight: 0.17 g
- Waveguide: HPS
BUILT-IN AMPLIFIERS:
- Number: 2
- Woofer: 1
- Type: PWM
- Amp. Power RMS: 70 W
- Tweeter: 1
- Type: PWM
- Amp. Power RMS: 20 W
CONTROL OPTIONS:
- Input Sensitivity: Switchable +4 dBu / -10 dBV
- Gain: Yes
- High-Shelf: - 2 dB, 0 dB, +2 dB
- Low-Shelf: - 2 dB, 0 dB, +2 dB
INPUT CONNECTORS:
- Analog: XLR, RCA
- Input Impedance: 10 kOhm / 20 kOhm
GENERAL DATA:
- Panel: Rear
- Frequency Response: 33 Hz - 25 kHz
- THD > 80 Hz: 0.5 %
- Max. SPL per pair at 1 m: ≥118 dB
- Crossover Frequency: 2.6 kHz
- Max. Power Consumption: 150 W
- Weight: 21.6 lb (9.8 kg)
- Height x Width x Depth: 15.8" x 9.8 “ x 13.2“ (400 mm x 250 mm x 335 mm)
WARRANTY: 1 year
What Is In The Box
- Adam Audio T8V 8-inch Active Studio Monitors
- Power cord
- Quick Start Guide
Videos
Manufacture Description
ADAM AUDIO T8V
The T8V is an affordable, professional 2-way powered studio monitor with an 8˝ woofer and ADAM Audio’s latest addition to the T Series. Designed around the same technology, features and build quality as its smaller siblings, the T8V provides best-in-class characteristics and sound performance.
The T8V impresses with a multitude of features that bring real benefits to the user: The U-ART tweeter’s 4:1 velocity transfer ratio, in combination with the new Class D amplifiers’ high dynamic range, yield respective max. peak SPL of 118 dB per pair. The tweeter, which extends up to 25 kHz, works as a team with the HPS Waveguide. This allows an optimal radiation of the high frequencies, which means the advantage of a more controlled, larger usable sweet spot during monitoring. With a bass extension down to 33 Hz, the T8V is especially suitable for users who produce bass-heavy music.
