Onkyo TX-RZ50 9.2-Channel THX Certified AV Receiver
The TX-RZ50 delivers enormous power on-demand to highlight every nuance of the music, movies, and games you love.
Features:
- Dirac Live Room Correction
- Klipsch Optimize Mode
- Ultimate 4K Gaming Experience
- 11.2-Channel Processing
Recommended Products
Prepaid Product
Customer Also Viewed
Samma3a Review
Technical Specification
AMPLIFIER
- Power output (All channels) 250 W/Ch (6 ohms, 1 kHz, 10% THD, 1 channel driven) 120 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08% THD, 2 channels driven, FTC)
- Dynamic power 250 W (3 ohms, Front) 220 W (4 ohms, Front) 130 W (8 ohms, Front)
- THD+N (Total Harmonic Distortion + Noise) 0.08% (20 Hz–20 kHz, half power)
- Input sensitivity and impedance 200 mV rms/47 k-ohms (Line) 3.5 mV rms/47 k-ohms (Phono MM)
- Rated RCA output level and impedance 1 V rms/470 ohms (Subwoofer pre-out) 200 mV rms/470 ohms (Zone 2/Zone B line-out)
- Frequency response 5 Hz–100 kHz/+1 dB, -3 dB (Direct Mode)
- Tone control ±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble)
- Signal-to-noise ratio 106 dB (Line, IHF-A) 80 dB (Phono, IHF-A)
- Speaker impedance 4–16 ohms
TUNER
- FM 87.5 MHz–107.9 MHz
- AM 530 kHz–1,710 kHz
- FM/AM preset memory 40 stations
GENERAL
- Power supply AC 120 V~, 60 Hz
- Power consumption (operating) 850 W
- Power consumption (idle) 75 W
- Power consumption (standby) 0.1 W
- Dimensions (W x H x D) 17 1/8˝ x 7 15/16˝ x 15 11/16˝ (435 x 201.5 x 398 mm)
- Weight 30.9 lbs. (14.0 kg)
CARTON
- Dimensions (W x H x D) 22 7/16˝ x 13 3/16˝ x 19 5/16˝ (570 x 335 x 490 mm)
- Weight 37.5 lbs. (17.0 kg)
What Is In The Box
- Onkyo TX-RZ50 9.2-Channel THX Certified AV Receiver x 1
- Power cord x 1
- Indoor FM antenna x 1
- AM loop antenna x 1
- Speaker setup microphone x 1
- Quick Start Guide x 1
- Remote control x 1
- Two AAA (R03) batteries x 1
Videos
Manufacture Description
Take the room out of the equation
State-of-the-art Dirac Live Room Correction technology unlocks your loudspeakers' full potential, improving audio performance across the full frequency band without additional upgrades. Dirac Live automatically calibrates sound in your room using either your smartphone and the included wired mic or virtually wireless with the Dirac Live PC or MacOS* application and a 3rd party USB mic (not included). Now, you'll get a more accurate measurement of your surround sound system's positioning to be more precise and balanced, providing a better result with the increased upper limit of delay time from 20 to 50 milliseconds.
HDMI 2.1 with 8K
HDMI® 2.1 is the most recent update of the HDMI® spec and supports eARC, a range of higher video resolutions and refresh rates including 8K60 and 4K120, and Dynamic HDR formats. 8K delivers a super-immersive viewing experience with 2x the horizontal and vertical resolution of 4K, and 4 times as many pixels; and combined with 60Hz refresh rate enables smooth and sharp viewing of content with high-speed action. HDMI 2.1 with 8K and eARC ensures your system is ready for the clearest and cleanest picture available both now and down the road.
