Roland BRIDGE CAST Dual Bus Gaming Mixer - Black
Take online gaming sound to the next level with BRIDGE CAST, your all-in-one solution for premium livestream audio. This customizable desktop hub is packed with secret weapons to take out the competition, including dual sound mixes, vocal transformer effects, music playback, sound effects, and support for a broadcast-grade mic and headphones. In the heat of the battle, BRIDGE CAST ensures that your audio is always as epic as your gameplay.
Features:
- Professional audio streaming interface and mixer designed for online gamers
- Powerful 32-bit hardware DSP allows you to dedicate all your computer resources to gaming and streaming
- Create independent mixes for you and the online audience with dual audio busses
- USB-C connectivity with Windows and Mac computers and mobile devices
- Also works with the Sony PlayStation®5 console and Nintendo Switch*
- High-quality XLR microphone preamp with phantom power for broadcast-grade mics
- Headphones jack with a professional high-sensitivity output and support for a headset or inline mic
- 5.1 or 7.1 USB virtual surround sound audio and 10-band EQ**
- Hands-on knobs and buttons for quick sound control
- Solid, streamlined design with customizable faceplate and adjustable knob LED colors
- Available in Black or Ice White finish
- Voice Changer effects derived from the Roland VT series
- High-quality vocal processing: EQ, compressor, noise suppressor, de-esser, and reverb
- Enhance your gaming performance with five customizable Game EQ presets
- Delay function to synchronize audio with video when needed
- Aux input for playing audio from a smartphone or external device
- Customize settings and save hardware configurations with the BRIDGE CAST app
Recommended Products
Prepaid Product
Customer Also Viewed
Samma3a Review
Technical Specification
- Input Channel:
- MIC
- AUX
- CHAT
- GAME
- MUSIC
- SYSTEM
- USB
- Output Channel:
- LINE OUT
- PHONES
- MIC
- STREAM
- PERSONAL
- USB
- Connectors:
- MIC jack: XLR type (Phantom power DC 48 V, 6 mA Max)
- PHONES/HEADSET jack: Stereo miniature phone type (CTIA, PLUG-IN power)
- AUX jack: Stereo miniature phone type (TRRS)
- LINE OUT jack: Stereo miniature phone type (TRS)
- USB port: USB Type-C (R)
- USB DC 5V port: USB Type-C
- Audio Mixing Bus: 2 (STREAM MIX, PERSONAL MIX)
- Sampling Frequency:
- Windows: 44.1 kHz, 48 kHz, 96 kHz
- macOS/iOS/Other: 48 kHz
- Signal Processing: AD/DA: 24 bits
- Internal Processing: 32-bit Floating point
- Effects:
- MIC: Voice Changer, Noise Suppressor, Compressor, Equalizer, De-esser, Reverb, Low Cut
- CHAT: De-esser, Compressor
- GAME: Equalizer
- STREAM: Delay
- Audio File Player:
- Number of tracks: 2
- Data Formats: WAV (Linear PCM, 48 kHz, 16 bits, stereo/mono)
- Maximum Time: 5 seconds/trackInput LevelMIC: -85.5--10.5 dBu (Maximum: +1.5 dBu)
- HEADSET MIC: -58.5--20.5 dBu (Maximum: -8.5 dBu)
- AUX: -10 dBu (Maximum: +2 dBu)
- Input Impedance:
- MIC: 3.4 k ohms
- HEADSET MIC: 1.3 k ohms
- AUX: 10 k ohms
- Output Level:
- LINE OUT: -4 dBu (Maximum: +8 dBu)
- PHONES/HEADSET: -1 dBu (Maximum: +11 dBu)
- PHONES/HEADSET: 78 mW + 78 mW (32 ohms)
- PHONES/HEADSET: 35 mW + 35 mW (250 ohms)
- Output Impedance:
- LINE OUT: 1 k ohm
- PHONES/HEADSET: 10 ohms
- Power:
- USB bus power
- USB AC adaptor (commercially available)
- Current Draw: 5 V DC, 900 mA
- Width: 222 mm
- Depth: 110 mm
- Height: 70 mm
- Weight: 450 g
- Warranty: 1 year
What Is In The Box
- Roland BRIDGE CAST Dual Bus Gaming Mixer
- Leaflet "Read Me First"
- USB 2.0 Type-C to Type-C Cable (2 m, 6.5 feet)
- USB 2.0 Type-C to Type-A Cable (2 m, 6.5 feet)
Videos
Manufacture Description
Amp Up Your Sound
BRIDGE CAST lets you chat and interact using a broadcast-grade dynamic or condenser microphone, the foundation of any professional audio setup. The high-performance XLR mic preamp delivers clear, dynamic sound in the box, with no need for messy external add-ons. You get superior audio monitoring too, with a powerful headphone amplifier and high-sensitivity output for pro-quality phones. The versatile headphones connector also supports a headset mic for a quick, single-cable connection.
Direct Sound Control
Along with a headphones output, BRIDGE CAST has a line output for external gaming speakers. Level knobs for each output let you easily control volumes and smoothly transition between phones and speakers during gameplay. There’s also a dedicated streaming level control to dial in the sound for your online audience.
The Vocal Shapeshifter
Morph your voice and become your character with fun processing derived from Roland’s famous VT voice transformer products. Adjust the pitch and formant to change your age or gender. Or go even further and take on the persona of a beast or alien.
BRIDGE CAST also includes EQ, compression, and other pro vocal processing to level up your streams. A low-cut filter softens pesky “P” and “T” plosives, while the de-esser cleans up harsh “S” tones. There’s a noise suppressor to throttle background distractions, plus reverb to launch your voice into another dimension. And with the muscular hardware DSP handling the audio load, all your computer power is dedicated to gaming and streaming.
Virtual Surround Sound
Immerse yourself in 5.1 or 7.1 virtual surround sound for headphones and stereo speaker systems, powered by advanced Roland technology. Audio is converted from a PC to virtual surround sound via a USB connection, delivering a powerful and engaging sound experience.
Roland BRIDGE CAST
Questions & Answers in English
What makes the Roland BRIDGE CAST ideal for streaming and podcasting?
The BRIDGE CAST delivers exceptional audio quality with pro-level controls made for creators and streamers. It lets you mix voice, game audio, and background music seamlessly, with real-time effects and studio-grade clarity.
Can it be used with a computer or gaming console?
Yes, it connects easily via USB for use with PCs or consoles, making it perfect for live streaming and content creation. You can control each audio source independently for a balanced and professional mix.
Is it suitable for beginners?
Definitely. Its intuitive layout and smart design make it easy to set up and operate, even for newcomers. You can start streaming with professional-quality sound in minutes without complex gear.
Available now at Samma3a.com with fast shipping and official warranty.
Looking for a high-quality streaming audio interface? The Roland BRIDGE CAST gives you full control over your mix, with crisp sound and an elegant, user-friendly design. Available now at Samma3a.com with fast shipping and official warranty.
Keywords: Roland, BRIDGE CAST, streaming mixer, podcast interface, audio controller, live stream, content creator, professional sound.
